How to use the pleater

Here is the basic layout of the Princess, showing the direction of fabric in pleating

Never operate the machine fast. Never allow children to touch it or components. Careless use could trap fingers between the rollers, ouch!

Remove packing tape and the machine is ready for use, but read these instructions first. The front of the machine is where the fabric is fed in. The back is where the fabric emerges. The right-hand axle from the front has left-hand thread. The left axle has right-hand thread. Use the machine either way round with one or both handles, whichever suits.

The Princess all-British Pleater enables you to gather fabrics for smocking, elasticating, shibori, etc. It will save you time and trouble with those tedious tasks, and let you get on with more enjoyable work.

High-quality materials throughout. The base is varnished dense wooden fibre board. The side plates are solid aluminium, solid brass is used for the rollers. No adjustment should be needed, but it is important not to overtighten the screws holding the side plates to the baseboard.

OPERATION

Thread as many needles as you need with the lengths of thread or elastic you require. You can remove any unwanted needles to save making needle holes in fabric where you want to avoid holes. See the section on changing or moving needles. Try a test piece first in case your first attempt would damage some valuable fabric. There might be some oil or transit grime left on the rollers – practice makes perfect.

Best way is to roll your fabric around a wooden dowel stick about 10 to 20mm. thick, of suitable length. We do not supply the stick with the machine as your requirements will vary according to the size of the fabric pieces you want to use. It helps to attach the end of the fabric to the stick with adhesive tape for stability.

Then slide the rolled fabric (on the stick) through the side loops of the upright coloured plates through which the rollers run, with the fabric coming off the bottom of the roll. Feed the leading straight edge of the fabric into the teeth of the top and bottom front rollers while turning the knobs gently, carefully ensuring that the fabric is taken up straight and evenly, as the start will determine the quality of the gathering across the whole piece.

Keeping the tension even all the way across the fabric is important, this can take a few attempts to get right. You can use either or both turning knobs plus an extra dowel stick laid over the fabric as it comes off the bottom of the first dowel stick. This second stick will need to be about 28cm. in length.

This second stick can be quite thick if you wish. What it does is to keep the tension even across the width of the fabric, while you have two hands free to turn the knobs. As you turn the knobs the fabric will pass through the rollers, emerging onto the needles and you will need to pull it onto the threads to keep the needles clear.

If you meet strong resistance as you turn the knobs it may mean the fabric is becoming folded. If this happens you can reverse up to a quarter turn of the knobs to release jammed fabric, but it is best avoided by making sure the fabric is taken up straight and not folded as it passes through.

FABRIC TENSION AND FINE SMOCKING

Probably the most important detail which affects the quality of the gathering you will achieve is the tension of the fabric. If there is too much ‘pull’ against the direction of movement of the fabric, you will put stress on the needles and possibly tear a fine fabric. Conversely if there is no tension (or different tensions across the fabric width) you are more likely to have ‘off line’ or unevenly gathered fabric, or even missed gathers. Again practise makes perfect and lots of users use no dowel quite effectively. It all depends on your individual style.

By now you should have some gathered fabric – and that is all there is to it. Occasionally needles may break and these are easily changed.

There are half-spaced grooves the full width of the rollers to be used if you wish to do very fine smocking. Simply move the needles or use extra ones to fill as many of these positions as you need.

CHANGING, MOVING, REPLACING NEEDLES

Using a small screwdriver inserted in the slot in the black circular roller holders. These are recessed into the coloured side plates and they hold the removable roller in position. Push the slots to the vertical position and the roller can be lifted out or levered gently using your screwdriver.

Now the needles will lift out easily and go back positioned just between the top and bottom front rollers where the fabric feeds in. The shoulder of the needle rests on the bottom back roller, the top back roller keeps the needles in place while gathering.

SPARE NEEDLES
Spare needles are available in packs of 16 at £7.50 for one pack, or £14.00 for two packs. For heavy users we do offer a lower price of £70.00 for 10 packs. These prices include UK post and packing.

REPAIR AND TOOLS
We do not supply any specific tools because all you are likely to need is a small screwdriver. To dismantle the machine (and it is very simple) for major cleaning or repairs you will need a cross-headed stubby screwdriver to loosen the screws under the bottom of the baseboard.

Alignment is important, so is light lubrication. PRINCESS PLEATERS is owned by Geoffrey Magnay, and he will do all he can to ensure you have years of trouble-free use from your Princess.

CARE AND GUARANTEE

Keep the machine away from dampness and water as this would damage it permanently. An occasional wipe of the rollers with a cloth dampened in methylated spirit will remove any accumulated dirt. Light machine oil could be applied to the roller axle pivots very sparingly after a great deal of use, but remember to run scrap cloth through repeatedly after oiling to avoid damaging valuable fabrics.

The machine will be best kept in its original box, when not in use to keep dust and accidental damage away. Dropping the machine is likely to cause permanent damage and misalignment. It will be best to keep the box and packing material anyway, in case you ever need to return the machine to us.

The machine is guaranteed against faulty workmanship and materials. Needles are only guaranteed against manufacturing faults as misuse will break them prematurely and they are regarded as expendable spares. This does not affect your statutory rights.

Our prices

GB Pounds, including packing and delivery...

THE PRINCESS PLEATER,
UK: £195.00, Europe: £230.00, USA: £235.00

Extra Princess needles (UK prices)...
£7.50 per pack of 16
£14.00 for two packs of 16
£70.00 for 10 packs of 16

We also stock needles for Read, Stanley and Amanda machines. See these needles.
